Displacement Transducers

Kyowa's displacement transducers are designed to measure relative displacement and/or absolute displacement from a steady point of structures by converting detected displacement to voltage. They are available in rated capacities ranging from 2mm to 5m and in different conversion systems. Important Notice Unless specified, strain-gage transducers must not be used under hydrogen environment.
