Acceleration transducers

Smallest damped type acceleration transducer (compared to other products in our lineup) Since it is a damping type, it is an acceleration transducer that is less affected by resonance due to crash acceleration. Rated Capacity: ±9807 m/s² Dimensions: 7 × 4.6 × 4.6 mm Rated Output: 3 mV/V or more Frequency Response (at 23ºC): 　DC to 1 kHz (Sensitivity deviation ±3%) 　1 kHz to 4 kHz (Sensitivity deviation ±10%)

Ultra-small and lightweight piezoelectric (IEPE) transducers with built-in amplifier and removable cable. Rated Capacity: ±4500 m/s² Dimensions: ϕ6.4 x 3.6 mm Voltage Sensitivity: 1.0 mV/m/s² ±10% Power Supply: 21 to 30V DC, 2 to 10mA

Ultra-small charge output piezoelectric acceleration transducers that support high/low temperatures, due to not having a built-in amplifier, and offer superior environmental resistance and impact resistance. Rated Capacity: ±100000 m/s² Dimensions: ϕ3.5 x 2.5 mm Electric Charge Sensitivity: 0.035 pC/m/s² ±20%

Piezoelectric (IEPE) transducers with a built-in amplifier and wide measuring range, capable of measuring from slight vibration to large acceleration. Rated Capacity: ±450 to ±4500 m/s² Dimensions:10 × 10 × 10 mm Voltage Sensitivity: 1.0 to 10 mV/m/s² ±10% Power Supply: 21 to 30 V DC, 2 to 10 mA

Compact and robust triaxial sensors (transducers) that use micro electro mechanical systems (MEMS). Rated Capacity: ±19.61, ±49.03 m/s² Dimensions: 10×5.8×14 mm Rated Output: 2 V

Compact and robust sensors (transducers) that use micro electro mechanical systems (MEMS). Rated Capacity: ±980.7 m/s², ±1961 m/s² Dimensions: 15 W × 6.3 H × 11 D mm Rated Output: 2 V ±20% Frequency Response: DC to 2k Hz

Compact, small-capacity transducers that use oil damped type strain gages. Rated Capacity: ±9.807 to ±196.1 m/s² Dimensions: 14 x 18 x 14 mm Rated Output: 0.5 mV/V or more Frequency Response: DC to (40 to 250) Hz

Compact, small-capacity transducers that use oil damped type strain gages. Rated Capacity: ±9.807 to ±196.1 m/s² Dimensions: 14 x 20 x 14 mm Rated Output: 0.5 mV/V or more Frequency Response: DC to (40 to 250) Hz

Triaxial transducers with three compact and lightweight acceleration transducers integrated in the same case, to simultaneously measure acceleration in the X, Y, and Z directions. Rated capacity: ±9.807 to 196.1 m/s² Dimension: 44×44×20 mm Rated output: 0.5 mV/V or more Frequency Response: DC to (40 to 250) Hz

Compact and lightweight undamped type transducers using a sputter type strain gage. Rated Capacity: ±9807, ±19613 m/s² Dimensions: 10 x 4.7 x 12.5 mm Rated Output: 1.2 mV/V or more Frequency Response (at 23ºC): DC to 4 kHz, sensitivity deviation: ±5%

Compact and lightweight undamped type transducers using a sputter type strain gage. Rated Capacity: ±9807, ±19613 m/s² Dimensions: 10 x 4.7 x 12.5 mm Rated Output: 1.2 mV/V or more Frequency Response (at 23ºC): DC to 4 kHz, sensitivity deviation ±5%

Acceleration transducers compatible with built-in head-form impactors and leg-form impactors (Flex-PLI-GTR) used during pedestrian protection performance testing. Rated Capacity: ±980.7 to ±9807 m/s² Dimensions: 10 x 5 x 10 mm Rated Output: 0.5 mV/V or more (±980.7 m/s²), 1 mV/V or more (±4903 m/s²), 2 mV/V or more (±9807 m/s²) Frequency Response (23ºC): DC to 1 kHz for all models (Sensitivity deviation ±3%), 1 kHz to 2 kHz for ASE-A-100 (Sensitivity deviation ±10%) (±980.7 m/s²), 1 kHz to 4 kHz for ASE-A-500/1K (Sensitivity deviation ±10%) (±4903 m/s²)

Acceleration transducers compatible with built-in head-form impactors and leg-form impactors (Flex-PLI-GTR) used during pedestrian protection performance testing. Rated Capacity: ±980.7 to ±9807 m/s² Dimensions: 10 x 5 x 10 mm Rated Output: 0.5 mV/V or more (±980.7 m/s²), 1 mV/V or more (±4903 m/s²), 2 mV/V or more (±9807 m/s²) Frequency Response: (23ºC): DC to 1 kHz for all models (Sensitivity deviation ±3%), 1 kHz to 2 kHz for ASER-A (Sensitivity deviation ±10%) (±980.7 m/s²), DC to 1 kHz for ASER-A-500/1K (Sensitivity deviation ±3%) (±9807 m/s²)

Compact, high-capacity acceleration transducers with high response that use oil damped type strain gages. Rated Capacity: ±98.07 to ±9807 m/s² Dimensions: 16×16.5×16 mm (ASH-A-10 to 50) 15.2×15.5×14 mm (ASH-A-100 to 1K) Rated Output: 0.5 mV/V ±20% (ASH-A-10: ±25%)

Triaxial type acceleration transducers that use oil damped type strain gages. Rated Capacity: ±98.07 to ±9807 m/s² Dimensions: 44×20×37 mm (ASHT-A-10 to 50) 38×16×30 mm (ASHT-A-100 to 1K) Rated Output: 0.5 mV/V ±20% (ASHT-A-10: 0.5 mV/V ±25%)

Transducers which a semiconductor is applied to the sensing part. Rated Capacity: ±1961 m/s² Dimensions: 7.6 x 4.6 x 15 mm Rated Output: 1.3 mV/V or more Frequency Response: DC to 3.5 kHz at 23ºC (Sensitivity deviation: ±5%)

Compact and lightweight transducers using semiconductor strain gages for sensing parts measure vehicle acceleration during automotive crash testing. Rated Capacity: ±19613 m/s² (2000 G) Rated Output: 6 mV/V or more Frequency Response: DC to 2.8 kHz, sensitivity deviation: ±5% at 23ºC

Compact piezoelectric (IEPE) transducers with a built-in amplifier and wide measuring range, capable of measuring from slight vibration to large acceleration. Rated Capacity: ±2200 m/s² Dimensions: ϕ7.8 x 15.7 x Hex7 mm Voltage Sensitivity: 1.0 mV/m/s² ±10% Power Supply: 15 to 25 VDC, 0.5 to 5.0 mA

Compact piezoelectric (IEPE) transducers with a built-in amplifier and wide measuring range, capable of measuring from slight vibration to large acceleration. Rated Capacity: ±2200 m/s² Dimensions: ϕ8.5 x 11.5 x Hex9 mm Voltage Sensitivity: 1.0 mV/m/s² ±10% Power Supply: 15 to 25 VDC, 0.5 to 5.0 mA

Piezoelectric (IEPE) transducers with a built-in amplifier and wide measuring range, capable of measuring from slight vibration to large acceleration. Rated Capacity: ±360 to ±4000 m/s² Dimensions: 14.2 x 14.2 x 23.7 mm Voltage Sensitivity: 1.0 mV/m/s² ±10% or 10 mV/m/s² ±10% Power Supply: 21 to 24 VDC, 0.5 to 10 mA
